SimpliSolar Series
Solar Monitoring & Performance Optimization
"Maximize Every Ray."
SimpliSolar Series provides comprehensive monitoring and optimization for solar PV installations of any size. From residential rooftops to utility-scale solar farms, our connected devices deliver real-time production tracking, performance analytics, and proactive fault detection to maximize your solar investment.
Panel-Level
Monitoring
15 sec
Data Resolution
99.9%
Uptime SLA
25 Year
Data Retention
Product Line Overview
SimpliSolar Home
Residential
Up to 25 kW
- Inverter + panel monitoring
- WiFi connectivity
- Homeowner mobile app
- Energy production tracking
- Savings calculator
SimpliSolar Pro
Commercial & Industrial
25 kW - 1 MW
- String-level monitoring
- Cellular + Ethernet
- Multi-site dashboard
- Performance benchmarking
- API integration
SimpliSolar Utility
Utility Scale
1 MW+
- Combiner box monitoring
- SCADA integration
- Weather station input
- Curtailment management
- Revenue-grade metering
Hardware Components
📡 SimpliSolar Gateway
Central data collection hub that aggregates data from all monitoring points and transmits to the cloud.
- WiFi, Ethernet, and 4G LTE options
- RS-485 Modbus for inverter connection
- Local data buffering (30 days)
- DIN rail or wall mount
⚡ Panel Optimizer CTs
Current transformers for panel-level or string-level power monitoring without DC wiring modifications.
- Split-core design (no wire cutting)
- 100A, 200A, 400A sizes
- ±1% accuracy class
- UV-resistant outdoor rated
🌡️ Environmental Sensor
On-site weather monitoring for accurate performance ratio calculations.
- Irradiance sensor (pyranometer)
- Ambient temperature
- Module temperature (back-of-panel)
- Wind speed option
📊 Revenue Meter
ANSI C12.20 compliant meter for utility billing and REC verification.
- Bi-directional energy measurement
- ±0.2% revenue-grade accuracy
- PQ analysis (THD, PF, harmonics)
- Demand interval recording
SimpliSolar Cloud Platform
Real-Time Dashboard
Live production, consumption, and grid export visualization
Fault Detection
Automatic alerts for underperformance, inverter faults, and outages
Performance Analytics
PR, capacity factor, specific yield, degradation tracking
Financial Tracking
Revenue, savings, ROI, and payback calculations
Sustainability Reports
CO2 offset, trees equivalent, ESG compliance
API & Integration
REST API, Modbus, SCADA, BMS connectivity
Technical Specifications
SimpliSolar Gateway
Specification
Connectivity
Inverter Interfaces
Supported Inverters
Sensor Inputs
Data Resolution
Local Storage
Power Supply
Enclosure
Operating Temp
Dimensions
Certifications
Value
WiFi 802.11 b/g/n, Ethernet 10/100, 4G LTE Cat-M1
RS-485 Modbus RTU, RS-232, Ethernet Modbus TCP
SMA, Fronius, SolarEdge, Enphase, Huawei, ABB, GoodWe, 50+ others
8x analog (4-20mA, 0-10V), 4x digital, 2x pulse counter
15-second sampling, 1-minute cloud uploads
30 days offline buffering, auto-sync on reconnect
24V DC or 120-240V AC, <5W consumption
NEMA 4X / IP66, UV-resistant, DIN rail mount
-40°F to +158°F (-40°C to +70°C)
6" x 4" x 2" (152 x 102 x 51 mm)
FCC, CE, UL 61010, RoHS
Monitoring Capabilities by Product
Feature
Inverter Monitoring
String-Level Monitoring
Weather Station Integration
Revenue-Grade Metering
SCADA Integration
Multi-Site Portfolio View
API Access
Home
✓
—
—
—
—
—
—
Pro
✓
✓
✓
Optional
—
✓
✓
Utility
✓
✓
✓
✓
✓
✓
✓
Applications
Residential
Rooftop systems, home battery, net metering
Commercial
Office buildings, retail, warehouses
Industrial
Manufacturing, data centers, processing
Solar Farms
Utility-scale, community solar, IPPs
O&M Providers
Fleet management, performance guarantees
Asset Owners
Portfolio monitoring, investor reporting
Ready to Maximize Your Solar Investment?
Contact us for a system assessment and monitoring solution design.
